Everyone needs an Angel...
- Square shape
- Increased stability
- Improved sink rate
- Rapid inflation
- Semi-light construction
Paragliders
Everyone needs an Angel... Modern square rescue parachute designs have proven time and again to offer significantly better pendulum stability and sink rate performance than traditional round parachutes, whilst retaining the fast opening times that are critical for our safety. Designed and developed by the OZONE R&D Team, the Angel SQ includes all of his knowledge and experience to create the latest, most up to date development of the concept.
As it is for Ozone R&D Team members, the Angel SQ is the best tandem reserve parachute for sharing flights in safety and confidence. The combination of fast opening, great stability and low sink rate into a semi-light package provides a universal safe and reliable solution.
Designed and developed by the OZONE R&D Team, the Angel SQ includes all of his knowledge and experience to create the latest, most up to date development of the concept.
The principal advantage of the Angel SQ over a traditional round is in its increased stability. The increased stability combined with the Angel SQ’s excellent sink rate makes it a higher performance reserve than traditional rounds.
The Angel SQ uses the highest quality parachute materials: Porcher PN9, and Cousin Dyneema lines. These materials have been chosen for their optimum balance of durability, performance, small packing volumes and low weight to ensure reliable, safe deployments, even in the most extreme situations.
The Angel SQ is certified EN and LTF to the EN 12491 and LTF 91/09 standards.
Modern square rescue parachute designs have proven time and again to offer significantly better pendulum stability and sink rate performance than traditional round parachutes, whilst retaining the fast opening times that are critical for our safety. The Angel SQ has a relatively large surface area, yet is very light in weight, giving exceptional sink rate.
The Angel SQ really shines in its high pendulum stability, which can be even more important than sink rate performance. During the development process, which included many real-life test deployments,...
The Angel SQ is my reserve of choice thanks to its it's fast opening, great stability and easy repacking — as soon as we completed testing it, I began to use it for all of the flying I do whether it’s...
Certification loading (kg) |
---|
Surface (m²) |
Weight (kg)* |
Sink rate at max load (m/s) |
System Height (mm)** |
Certification |
180 | 220 |
---|---|
49 | 63.8 |
2.05 | 2.65 |
5.39 | 5.47 |
6035 | 6835 |
EN / LTF | EN / LTF |
*Weights with deployment bag and short bridle
**System Height: Apex line + upper apex line + short bridle
