- Easy nil wind inflation
- Short take off distance
- Ease of use
- Stability in turbulent air
- TST (tip steering system)
- Shark Nose technology
- Easy nil wind inflation
- Short take off distance
- Ease of use
- Stability in turbulent air
- TST (tip steering system)
- Shark Nose technology
Colour Options
Ordering Information
Package Contents
Your OZONE wing is delivered standard with the following accessories:
Inner Bag, Glider Strap, Riser bag, Speed Bar, OZONE Stickers, Repair Cloth, OZONE Keyring.
You may choose to add something to your order, such as: Easy Bag (stuff bag), Light Easy bag (video), Saucisse Bag (video) (concertina packing bag), Glider Backpack, or OZONE Clothing and Accessories.
Request
Photos
Specifications
| Sizes | 20 | 22 | 24 | 26 | 28 | 30 |
|---|---|---|---|---|---|---|
| Number of cells | 48 | 48 | 48 | 48 | 48 | 48 |
| Projected area (m2) | 17.2 | 18.9 | 20.6 | 22.4 | 24.1 | 25.8 |
| Flat Area (m^2) | 20 | 22 | 24 | 26 | 28 | 30 |
| Projected Span (m) | 7.98 | 8.32 | 8.69 | 9.04 | 9.39 | 9.71 |
| Flat Span (m) | 10.01 | 10.59 | 11.06 | 11.52 | 11.95 | 12.37 |
| Projected Aspect Ratio | 3.7 | 3.7 | 3.7 | 3.7 | 3.7 | 3.7 |
| Flat Aspect Ratio | 5.1 | 5.1 | 5.1 | 5.1 | 5.1 | 5.1 |
| Root Chord (m) | 2.54 | 2.67 | 2.79 | 2.9 | 3.01 | 3.11 |
| Glider Weight (kg) | 3.91 | 4.19 | 4.42 | 4.66 | 4.88 | 5.13 |
| PG Weight Range (kg) | 55-70 | 55-80 | 65-85 | 80-100 | 95-120 | 110-140 |
| PPG (DGAC) Weight Range (kg) | 55-100 | 55-105 | 65-120 | 80-140 | 95-160 | 110-190 |
| DGAC | DGAC | DGAC | DGAC | DGAC | DGAC | DGAC |
* Weights may vary up to 50gm per size due to slight variations in the manufacturing of the fabric used.
Materials
- Top Surface Cloth: Dominico N20D / Skytex 27 Classic
- Bottom Surface Cloth: Skytex 27 Classic
- Rib cloth: Dominico 30D FM / Skytex 27 Hard
- Upper lines: Liros DSL70
- Mid lines: Liros DSL70/140
- Lower Lines: Edelrid 6843-200/160
Custom Colours
OZONE COLOUR REFERENCE ()
